Fieldbus control with embedded fieldbus 305
OUTPUT SIGNAL SOURCE SELECTION ABB DRV DCU
1401 RELAY
OUTPUT 1
COMM
COMM(-1)
Enables relay output RO control by
signal 0134 COMM RO WORD.
40134 for signal
0134
1501 AO1
CONTENT
SEL
135 Directs the contents of the fieldbus
reference 0135 COMM VALUE 1 to
analog output AO.
40135 for signal
0135
SYSTEM CONTROL INPUTS ABB DRV DCU
1601 RUN
ENABLE
COMM Enables the control of the inverted
Run enable signal (Run disable)
through 0301 FB CMD WORD 1 bit 6
(RUN_DISABLE); with the ABB
drives profile 5319 EFB PAR 19 bit 3
(INHIBIT OPERATION).
40001
bit 3
40031
bit 6
1604 FAULT
RESET SEL
COMM Enables fault reset through the
fieldbus 0301 FB CMD WORD 1 bit 4
(RESET); with the ABB drives profile
5319 EFB PAR 19 bit 7 (RESET).
40001
bit 7
40031
bit 4
1606 LOCAL
LOCK
COMM Local control mode lock signal
through 0301 FB CMD WORD 1 bit
14 (REQ_LOCALLOC)
- 40031
bit 14
1607 PARAM
SAVE
DONE
SAVE…
Saves parameter value changes
(including those made through
fieldbus control) to permanent
memory.
41607
1608 START
ENABLE 1
COMM Inverted Start enable 1 (Start disable)
through 0302 FB CMD WORD 2
bit
18 (START_DISABLE1)
- 40032
bit 18
1609 START
ENABLE 2
COMM Inverted Start enable 2 (Start disable)
through 0302 FB CMD WORD 2 bit
19 (START_DISABLE2)
- 40032
bit 19
LIMITS ABB DRV DCU
2013 MIN
TORQUE
SEL
COMM Minimum torque limit 1/2 selection
through 0301 FB CMD WORD 1 bit
15 (TORQLIM2)
- 40031
bit 15
2014 MAX
TORQUE
SEL
COMM Maximum torque limit 1/2 selection
through 0301 FB CMD WORD 1 bit
15 (TORQLIM2)
- 40031
bit 15
2201 ACC/DEC
1/2 SEL
COMM Acceleration/deceleration ramp pair
selection through 0301 FB CMD
WORD 1 bit 10 (RAMP_2)
- 40031
bit 10
Parameter Setting for
fieldbus
control
Function/Information Modbus register
address
