172 Parameters
05.81 Output frequency at
fault
Displays the output frequency (01.06) at which fault occurred. -
-500.00…500.00
Hz
Output frequency at fault. See par.
46.02
05.82 DC voltage at fault Displays the DC link volt age (01.11) at which fault occurred. -
0.00…2000.00 V DC voltage at fault. 10 = 1 V
05.83 Motor current at
fault
Displays the motor current (01.07) at which fault occurred. -
05.84 Motor torque at fault Displays the motor torque (01.10) at which fault occurred. -
-1600.0…1600.0% Motor torque at fault. See par.
46.03
05.85 Main status word at
fault
Displays the main status word (06.11) at which fault occurred.
For the bit list, see parameter 06.11 Main status word.
0x0000
0x0000...0xffff Main status word at fault. 1 = 1
05.86 DI delayed status at
fault
Displays the DI delayed status (10.02) at which fault
occurred. For the bit list, see parameter 10.02 DI delayed
status.
0b0000
0b0000...0b1111 DI delayed status at fa ult. 1 = 1
05.87 Inverter
temperature at fault
Displays the inverter temperature (05.11) at which fault
occurred.
-
-40…160°C Inverter temperature at fault. 1 = 1°C
05.88 Reference used at
fault
Displays the reference used (28.01/23.01) at which fault
occurred. The type of the reference depends on the selected
operation mode (19.01).
-
No. Name/Value Description Def/FbEq16
Bit Name
0 Ready to switch ON
1 Ready run
2 Ready ref
3 Tripped
4 Not in use
5 Not in use
6 Not in use
7 Warning
8 Modulating
9 Remote
10 Net OK
11 User bit 0
12 User bit 1
13 User bit 2
14 Charging
15 User bit 3
