Parameters 171
05.10 Control board
temperature
Measured temperature of the control board. 0
-100… 300 °C Control board temperature in degrees Celsius or Fahrenheit. 1 = unit
05.11 Inverter
temperature
Estimated drive temperature in percent of fault limit. The fault
limit varies according to the type of the drive.
0.0% = 0 °C (32 °F)
100.0% = Fault limit
0
-40.0…160.0% Drive temperature in percent. 1 = 1%
05.20 Diagnostic word 1 Diagnostic word 1. For possible causes and remedies, see
chapter Fault tracing.
0b0000
0b0000...0b1111 Diagnostic word 1. 1 = 1
05.21 Diagnostic word 2 Diagnostic word 2. For possible causes and remedies, see
chapter Fault tracing.
0b0000
0b0000...0b1111 Diagnostic word 2. 1 = 1
05.22 Diagnostic word 3 Diagnostic word 3. For possible causes and remedies, see
chapter Fault tracing.
0b0000
0b0000...0b1111 Diagnostic word 3. 1 = 1
05.80 Motor speed at fault Displays the motor speed (01.01) at which fault occurred. -
-30000.00…
30000.00 rpm
Motor speed at fault. See par.
46.01
No. Name/Value Description Def/FbEq16
Bit Name Value
0 Any warning or fault Yes = Drive has generated a warning or tripped on a fault.
1 Any warning Yes = Drive has generated a warning.
2 Any fault Yes = Drive has tripped on a fault.
3 Reserved
4 Overcurrent flt Yes = Drive has tripped on fault 2310 Overcurrent.
5 Reserved
6 DC overvoltage Yes = Drive has tripped on fault 3210 DC link overvoltage.
7 DC undervoltage Yes = Drive has tripped on fault 3220 DC link undervoltage.
8 Reserved
9 Device overtemp flt Yes = Drive has tripped on fault 4310 Excess temperature.
10...15 Reserved
Bit Name Value
0...9 Reserved
10 Motor overtemperature fault Yes = Drive has tripped on fault 4981 External
temperature 1 or 4982 External temperature 2.
11...15 Reserved
Bit Name Value
0...8 Reserved.
9 kWh pulse 1 = kWh pulse is active.
10 Reserved.
11 Fan command. 1 = Drive fan is rotating above idle speed.
12...15 Reserved
