Parameters 259
Warning The external event generates a warning. 1
31.05 External event 3
source
Defines the source of external event 3. See also parameter
31.06 External event 3 type.
For the selections, see parameter 31.01 External event 1
source.
Inactive
(true)
31.06 External event 3
type
Selects the type of external event 3. Fault
Fault The external event generates a fault. 0
Warning The external event generates a warning. 1
31.07 External event 4
source
Defines the source of external event 4. See also parameter
31.08 External event 4 type.
For the selections, see parameter 31.01 External event 1
source.
Inactive
(true)
31.08 External event 4
type
Selects the type of external event 4. Fault
Fault The external event generates a fault. 0
Warning The external event generates a warning. 1
31.09 External event 5
source
Defines the source of external event 5. See also parameter
31.10 External event 5 type.
For the selections, see parameter 31.01 External event 1
source.
Inactive
(true)
31.10 External event 5
type
Selects the type of external event 5. Fault
Fault The external event generates a fault. 0
Warning The external event generates a warning. 1
31.11 Fault reset
selection
Selects the source of an external fault reset signal. The signal
resets the drive after a fault trip if the cause of the fault no
longer exists.
0 -
>
1 = Reset
Note: A fault reset from the fieldbus interface is always
observed regardless of this parameter.
Not used
Not used Not used. 0
Not used Not used. 1
DI1 Digital input DI1 (10.02 DI delayed status, bit 0). 2
DI2 Digital input DI2 (10.02 DI delayed status, bit 1). 3
DI3 Digital input DI3 (10.02 DI delayed status, bit 2). 4
DI4 Digital input DI4 (10.02 DI delayed status, bit 3). 5
DI5 Digital input DI5 (10.02 DI delayed status
, bit 4). 6
DI6 Digital input DI6 (10.02 DI delayed status, bit 5). 7
Timed function 1 Bit 0 of 34.01 Timed functions status (see page 273). 18
Timed function 2 Bit 1 of 34.01 Timed functions status (see page 273). 19
Timed function 3 Bit 2 of 34.01 Timed functions status (see page 273). 20
Supervision 1 Bit 0 of 32.01 Supervision status (see page 266). 24
Supervision 2 Bit 1 of 32.01 Supervision status (see page 266). 25
Supervision 3 Bit 2 of 32.01 Supervision status (see page 266). 26
Other [bit] Source selection (see Terms and abbreviations on page 162). -
No. Name/Value Description Def/FbEq16
