328 Parameters
50.07 FBA A actual 1 type Selects the type and scaling of actual value 1 transmitted to
the fieldbus network through fieldbus adapter A. The scaling
of the value is defined by parameters 46.01…46.04,
depending on which actual value type is selected by this
parameter.
Speed or
frequency
Speed or frequency Type and scaling is chosen automatically according to the
currently active operation mode as follows:
0
Transparent No scaling is applied. 1
General Generic reference without a specific unit. 2
Torque The scaling is defined by parameter 46.03 Tor qu e scal ing .3
Speed The scaling is defined by parameter 46.01 Speed scaling.4
Frequency The scaling is defined by parameter 46.02 Frequency scaling.5
50.08 FBA A actual 2 type Selects the type and scaling of actual value 2 transmitted to
the fieldbus network through fieldbus adapter A. The scaling
of the value is defined by parameters 46.01…46.04,
depending on which actual value type is selected by this
parameter.
Speed or
frequency
Speed or frequency Type and scaling is chosen automatically according to the
currently active operation mode as follows:
0
Transparent No scaling is applied. 1
General Generic reference without a specific unit. 2
Torque 01.01 Motor speed used is sent as actual value 2. The scaling
is defined by parameter 46.03 Tor qu e scaling .
3
Speed The scaling is defined by parameter 46.01 Speed scaling.4
Frequency The scaling is defined by parameter 46.02 Frequency scaling.5
50.09 FBA A SW
transparent source
Selects the source of the fieldbus status word when
parameter 50.06 FBA A SW sel is set to Transparent mode.
Not selected
Not selected No source selected. -
Other Source selection (see Terms and abbreviations on page 162). -
50.10 FBA A act1
transparent source
When parameter 50.07 FBA A actual 1 type is set to
Transparent, this parameter selects the source of actual value
1 transmitted to the fieldbus network through fieldbus adapter
A.
Not selected
Not selected No source selected. -
Other Source selection (see Terms and abbreviations
on page 162). -
No. Name/Value Description Def/FbEq16
Operation mode
(see par. 19.01)
Actual value 1 type
Speed control
Speed
Torque control
Frequency control Frequency
Operation mode
(see par. 19.01)
Actual value 2 type
Speed control
Speed
Torque control
Frequency control Frequency
