392 Additional parameter data
34.77 Exception 3 length Real 0…60 d 1 = 1 d
34.78 Exception day 4 Date - d 1 = 1 d
34.79 Exception day 5 Date - d 1 = 1 d
34.80 Exception day 6 Date - d 1 = 1 d
34.81 Exception day 7 Date - d 1 = 1 d
34.82 Exception day 8 Date - d 1 = 1 d
34.83 Exception day 9 Date - d 1 = 1 d
34.84 Exception day 10 Date - d 1 = 1 d
34.85 Exception day 11 Date - d 1 = 1 d
34.86 Exception day 12 Date - d 1 = 1 d
34.87 Exception day 13 Date - d 1 = 1 d
34.88 Exception day 14 Date - d 1 = 1 d
34.89 Exception day 15 Date - d 1 = 1 d
34.90 Exception day 16 Date - d 1 = 1 d
34.100 Timed function 1 PB 0b0000…0b1111 - 1 = 1
34.101 Timed function 2 PB 0b0000…0b1111 - 1 = 1
34.102 Timed function 3 PB 0b0000…0b1111 - 1 = 1
34.110 Boost time function PB 0b0000…0b1111 - 1 = 1
34.111 Boost time activation source Binary
src
--1 = 1
34.112 Boost time duration Duration 00 00:00…07 00:00 min 1 = 1 min
35 Motor thermal protection
35.01 Motor estimated temperature Real -60…1000 °C or
-76…1832 °F
°C or °F 1 = 1 °
35.02 Measured temperature 1 Real -60…5000 °C or
-76…9032 °F
°C, °F 1 = 1 unit
35.03 Measured temperature 2 Real -60…5000 °C or
-76…9032 °F
°C, °F 1 = 1 unit
35.05 Motor overload level Real 0.0...300.0 % 1 = 1unit
35.11 Temperature 1 source List --1 = 1
35.12 Temperature 1 fault limit Real -60…5000 °C or
-76…9032 °F
°C, °F 1 = 1 unit
35.13 Temperature 1 warning limit Real -60…5000 °C or
-76…9032 °F
°C, °F 1 = 1 unit
35.14 Temperature 1 AI source Analog
src
--1 = 1
35.21 Temperature 2 source List --1 = 1
35.22 Temperature 2 fault limit Real -60…5000 °C or
-76…9032 °F
°C, °F 1 = 1 unit
35.23 Temperature 2 warning limit Real -60…5000 °C or
-76…9032 °F
°C, °F 1 = 1 unit
35.24 Temperature 2 AI source Analog
src
--1 = 1
35.50 Motor ambient temperature Real -60…100 °C or
-76 … 212 °F
°C, °F 1 = 1 °
No. Name Type Range Unit FbEq32
