Additional parameter data 393
35.51 Motor load curve Real 50…150 % 1 = 1%
35.52 Zero speed load Real 50…150 % 1 = 1%
35.53 Break point Real 1.00 … 500.00 Hz 100 = 1 Hz
35.54 Motor nominal temperature
rise
Real 0…300 °C or 32…572 °F °C or °F 1 = 1 °
35.55 Motor thermal time const Real 100…10000 s 1 = 1 s
35.56 Motor overload action List 0...2 - 1 = 1
35.57 Motor overload class List 0...4 - 1 = 1
36 Load analyzer
36.01 PVL signal source Analog
src
--1 = 1
36.02 PVL filter time Real 0.00…120.00 s 100 = 1 s
36.09 Reset loggers List 0…3 - 1 = 1
36.10 PVL peak value Real -32768.00…32767.00 - 100 = 1
36.11 PVL peak date Data 1/1/1980...6/5/2159 - 1 = 1
36.12 PVL peak time Data 00:00:00...23:59:59 - 1 = 1
36.13 PVL current at peak Real -32768.00…32767.00 A 100 = 1 A
36.14 PVL DC voltage at peak Real 0.00…2000.00 V 100 = 1 V
36.15 PVL speed at peak Real -30000.00-30000.00 rpm 100 = 1 rpm
36.16 PVL reset date Data 1/1/1980...6/5/2159 - 1 = 1
36.17 PVL reset time Data 00:00:00...23:59:59 - 1 = 1
37 User load curve
37.01 ULC output status word PB 0b0000…0b1111 - 1 = 1
37.02 ULC supervision signal Analog
src
--1 = 1
37.03 ULC overload actions List 0…3 - 1 = 1
37.04 ULC underload actions List 0…3 - 1 = 1
37.11 ULC speed table point 1 Real -30000.0…30000.0 rpm 10 = 1 rpm
37.12 ULC speed table point 2 Real -30000.0…30000.0 rpm 10 = 1 rpm
37.13 ULC speed table point 3 Real -30000.0…30000.0 rpm 10 = 1 rpm
37.14 ULC speed table point 4 Real -30000.0…30000.0 rpm 10 = 1 rpm
37.15 ULC speed table point 5 Real -30000.0…30000.0 rpm 10 = 1 rpm
37.21 ULC underload point 1 Real -1600.0…1600.0 % 10 = 1%
37.22 ULC underload point 2 Real -1600.0…1600.0 % 10 = 1%
37.23 ULC underload point 3 Real -1600.0…1600.0 % 10 = 1%
37.24 ULC underload point 4 Real -1600.0…1600.0 % 10 = 1%
37.25 ULC underload point 5 Real -1600.0…1600.0 % 10 = 1%
37.31 ULC overload point 1 Real -1600.0…1600.0 % 10 = 1%
37.32 ULC overload point 2 Real -1600.0…1600.0 % 10 = 1%
37.33 ULC overload point 3 Real -1600.0…1600.0 % 10 = 1%
37.34 ULC overload point 4 Real -1600.0…1600.0 % 10 = 1%
No. Name Type Range Unit FbEq32
