402 Additional parameter data
53 FBA A data out
53.01 FBA A data out1 List 0...3, 11...13, 21 - 1 = 1
…… … … …
53.12 FBA A data out12 List 0...3, 11...13, 21 - 1 = 1
58 Embedded fieldbus
58.01 Protocol enable List 0…1 - 1 = 1
58.02 Protocol ID Real 0000h…FFFFh - 1 = 1
58.03 Node address Real 0…255 - 1 = 1
58.04 Baud rate List 0…7 - 1 = 1
58.05 Parity List 0…3 - 1 = 1
58.06 Communication control List 0…2 - 1 = 1
58.07 Communication diagnostics PB 0000h…FFFFh - 1 = 1
58.08 Received packets Real 0…4294967295 - 1 = 1
58.09 Transmitted packets Real 0…4294967295 - 1 = 1
58.10 All packets Real 0…4294967295 - 1 = 1
58.11 UART errors Real 0…4294967295 - 1 = 1
58.12 CRC errors Real 0…4294967295 - 1 = 1
58.14 Communication loss action List 0…5 - 1 = 1
58.15 Communication loss mode List 1…2 - 1 = 1
58.16 Communication loss time Real 0.0…6000.0 s 10 = 1 s
58.17 Transmit delay Real 0…65535 ms 1 = 1 ms
58.18 EFB control word PB 0000h…FFFFh - 1 = 1
58.19 EFB status word PB 0000h…FFFFh - 1 = 1
58.25 Control profile List 0, 5 - 1 = 1
58.26 EFB ref1 type List 0…5 - 1 = 1
58.27 EFB ref2 type List 0…5 - 1 = 1
58.28 EFB act1 type List 0…5 - 1 = 1
58.29 EFB act2 type List 0…5 - 1 = 1
58.31 EFB act1 transparent source Analog
src
--1 = 1
58.32 EFB act2 transparent source Analog
src
--1 = 1
58.33 Addressing mode List 0…2 - 1 = 1
58.34 Word order List 0…1 - 1 = 1
58.101 Data I/O 1 Analog
src
--1 = 1
58.102 Data I/O 2 Analog
src
--1 = 1
58.103 Data I/O 3 Analog
src
--1 = 1
58.104 Data I/O 4 Analog
src
--1 = 1
No. Name Type Range Unit FbEq32
