Additional parameter data 403
58.105 Data I/O 5 Analog
src
--1 = 1
58.106 Data I/O 6 Analog
src
--1 = 1
58.107 Data I/O 7 Analog
src
--1 = 1
…… ………
58.114 Data I/O 14 Analog
src
--1 = 1
70 Override
70.01 Override status PB 0b0000…0b1111 - 1 = 1
70.02 Override enable List --1 = 1
70.03 Override activation source List --1 = 1
70.04 Override reference source List --1 = 1
70.05 Override direction List --1 = 1
70.06 Override frequency Real -500.0…500.0 Hz 100 = 1 Hz
70.07 Override speed Real -30000.0…30000.0 rpm 100 = 1 rpm
70.20 Override fault handling List 0...1 - 1 = 1
70.21 Override auto reset trials Real 0...60 - 1 = 1
70.22 Override auto reset time Real 0.1...120.0 s 10 = 1
71 External PID1
71.01 External PID act value Real -200000.00…200000.00 % 100 = 1 PID
customer unit
71.02 Feedback act value Real -200000.00…200000.00 PID
customer
units
100 = 1 PID
customer unit
71.03 Setpoint act value Real -200000.00…200000.00 PID
customer
units
100 = 1 PID
customer unit
71.04 Deviation act value Real -200000.00…200000.00 PID
customer
units
100 = 1 PID
customer unit
71.06 PID status word PB 0000h…FFFFh - 1 = 1
71.07 PID operation mode List 0…2 - 1 = 1
71.08 Feedback 1 source Analog
src
--1 = 1
71.11 Feedback filter time Real 0.000…30.000 s 1000 = 1 s
71.14 Setpoint scaling Real -200000.00…200000.00 - 100 = 1
71.15 Output scaling Real -200000.00…200000.00 - 100 = 1
71.16 Setpoint 1 source Analog
src
--1 = 1
71.19 Internal setpoint sel1 Binary
src
--1 = 1
71.20 Internal setpoint sel2 Binary
src
--1 = 1
No. Name Type Range Unit FbEq32
