404 Additional parameter data
71.21 Internal setpoint 1 Real -200000.00…200000.00 PID
customer
units
100 = 1 PID
customer unit
71.22 Internal setpoint 2 Real -200000.00…200000.00 PID
customer
units
100 = 1 PID
customer unit
71.23 Internal setpoint 3 Real -200000.00…200000.00 PID
customer
units
100 = 1 PID
customer unit
71.26 Setpoint min Real -200000.00…200000.00 - 100 = 1
71.27 Setpoint max Real -200000.00…200000.00 - 100 = 1
71.31 Deviation inversion Binary
src
--1 = 1
71.32 Gain Real 0.10…100.00 - 100 = 1
71.33 Integration time Real 0.0…9999.0 s 10 = 1 s
71.34 Derivation time Real 0.000…10.000 s 1000 = 1 s
71.35 Derivation filter time Real 0.0…10.0 s 1000 = 1 s
71.36 Output min Real -200000.00…200000.00 - 10 = 1
71.37 Output max Real -200000.00…200000.00 - 10 = 1
71.38 Output freeze enable Binary
src
--1 = 1
71.39 Deadband range Real 0.0…200000.0 - 10 = 1
71.40 Deadband delay Real 0.0…3600.0 s 1000 = 1 s
71.58 Increase prevention Binary
src
--1 = 1
71.59 Decrease prevention Binary
src
--1 = 1
71.62 Internal setpoint actual Real -200000.00…200000.00 PID
customer
units
100 = 1 PID
customer unit
71.79 External PID units List 0...31 Depends
on
selection
-
76 PFC configuration
76.01 PFC status PB 0b0000...0b1111 - 1 = 1
76.02 PFC system status PB 0...9, 100...103, 200...202,
300...302, 400, 500, 600,
700, 800, 801
-1 = 1
76.11 Pump/fan status 1 PB 0b0000…0b1111 - 1 = 1
76.12 Pump/fan status 2 PB 0b0000…0b1111 - 1 = 1
76.13 Pump/fan status 3 PB 0b0000…0b1111 - 1 = 1
76.14 Pump/fan status 4 PB 0b0000…0b1111 - 1 = 1
76.21 PFC configuration List 0, 2…3 - 1 = 1
76.25 Number of motors Real 1…4 - 1 = 1
76.26 Min number of motors allowed Real 0…4 - 1 = 1
76.27 Max number of motors allowed Real 1…4 - 1 = 1
No. Name Type Range Unit FbEq32
