The following table shows the values of selected DC voltage levels. The drive DC
voltage limits are calculated based on the parameter 95.01 Supply voltage and 95.02
Adaptive voltage limits.
Notes:
• parameter 95.03 Estimated AC supply voltage is the estimated voltage during
start-up of the drive and is not continuously updated during the time lim eit.
• The absolute voltages vary according to the drive/inverter type and AC supply
voltage range.
DC Voltage level
[V]
95.01 Supply voltage
AC supply voltage range [V]
380…415
AC supply voltage range [V]
440…480
Automatic/Not selected
Overvoltage fault
limit
842 842 842
Overvoltage
control limit
779 779 779
Internal brake
chopper start
limit
779 779 779
Internal brake
chopper stop
limit
759 759 759
Overvoltage
warning limit
745 745 745
Undervoltage
warning limit
0.85×1.41×par 95.03 value
1)
0.85×1.41×par 95.03 value
1)
0.85×1.41×par 95.03
value
1)
0.85×1.35×380 = 436
2)
0.85×1.35×440 = 463
2)
0.85×1.35×440 = 463
2)
Undervoltage
control limit
0.78×1.41×par 95.03 value
1)
0.78×1.41×par 95.03 value
1)
0.78×1.41×par 95.03
value
1)
0.78×1.35×380 = 400
2)
0.78×1.35×440 = 463
2)
0.78×1.35×440 = 463
2)
Charging relay
closing limit
0.78×1.41×par 95.03 value
1)
0.78×1.41×par 95.03 value
1)
0.78×1.41×par 95.03
value
1)
0.78×1.35×380 = 400
2)
0.78×1.35×440 = 463
2)
0.78×1.35×440 = 463
2)
Charging relay
opening limit
0.73×1.41×par 95.03 value
1)
0.73×1.41 ×par 95.03 value
1)
0.73×1.41 ×par 95.03
value
1)
0.73×1.35×380 = 374
2)
0.73×1.35×440 = 433
2)
0.73×1.35×440 = 433
2)
Undervoltage
fault limit
0.73×1.41×par 95.03 value
1)
0.73×1.41×par 95.03 value
1)
0.73×1.41×par 95.03
value
1)
0.73×1.35×380 = 374
2)
0.73×1.35×440 = 433
2)
0.45×1.35×440 = 433
2)
DC voltage at
upper bound of
supply voltage
range (U
DCmax
)
560 648 648
DC voltage at
lower bound of
supply voltage
range (U
DCmin
)
513 594 594
