80 Program features
A warning A3A2 DC link undervoltage is generated during any of the below conditions
occurs:
• When drive is not modulating and the DC link voltage 01.11 DC voltage is below
85% of the undervoltage warning limit.
• The drive is modulating, the DC link voltage 01.11 DC voltage is below 73% of the
standby limit and the parameter 21.18 Auto restart time > 0. The warning
continues to appear if the DC link voltage is continuously less than the standby
limit until auto restart time elapses.
Note: Control board must be externally powered with 24 VDC to enable warning
in this condition. Else, the control switches off once the DC voltage goes below
hardware limit.
A fault 3220 DC link undervoltage is generated during any of the below conditions:
• The DC link voltage 01.11 DC voltage value is less than the undervoltage trip limit
and the parameter 21.18 Auto restart time is not enabled.
• The DC link voltage 01.11 DC voltage value is less than the undervoltage trip limit
and the parameter 21.18 Auto restart time is enabled. The undervoltage trip
occurs only if the warning continues to appear until auto restart time elapses.
Notes:
• Control board must be externally powered with 24 VDC to enable warning in
this condition. Else, the control switches off once the DC voltage goes below
the hardware limit.
• DC voltage stabilization parameter is available in service level parameters list.
For more information, contact your local ABB representative.
Settings
Parameters 01.11 DC voltage (page 165), 30.30 Overvoltage control (page 256),
30.31 Undervoltage control (page 256), 95.01 Supply voltage (page 352) and 95.02
Adaptive voltage limits (page 353).
Charging
activation/
standby limit
3)
0.73×1.41×par 95.03 value
1)
0.73×1.41×par 95.03 value
1)
0.73×1.41×par 95.03
value
1)
0.73×1.35×380 = 374
2)
0.73×1.35×440 = 433
2)
0.73×1.35×440 = 433
2)
1)
Parameter Adaptive voltage limits is set to Enable
2)
Parameter Adaptive voltage limits is set to Disable
3)
When standby is activated, drive modulation is stopped, the fan is stopped and the pre-charge circuit is
activated. If the voltage exceeds this level again, the drive has to complete charging before it will
automatically continue operation.
DC Voltage level
[V]
95.01 Supply voltage
AC supply voltage range [V]
380…415
AC supply voltage range [V]
440…480
Automatic/Not selected
