284 Parameters
91
91 Encoder module
settings
Configuration of encoder interface modules.
0000 0000b …
0011 0011b
Status word of digital inputs on FEN-xx modules. 1 = 1
91.02 Module 1 status Displays the type of the interface module found in the location
specified by parameter 91.12 Module 1 location.
This parameter is read-only.
-
No option No module detected in the specified slot. 0
No communication A module has been detected but cannot be communicated
with.
1
Unknown The module type is unknown. 2
FEN-01 An FEN-01 module has been detected and is active. 16
FEN-31 An FEN-31 module has been detected and is active. 21
91.04 Module 1
temperature
Displays the temperature measured through the sensor input
of interface module 1.
Note: With a PTC sensor, the unit is ohms.
This parameter is read-only.
-
0…1000 °C, or ohm Temperature measured through interface module 1. -
91.10 Encoder parameter
refresh
Validates any changed encoder interface module parameters.
This is needed for any parameter changes in groups 90…93
to take effect.
After refreshing, the value reverts automatically to Done.
Notes:
• Permanent magnet motors only: The drive will perform a
fresh autophasing routine (see page 51) at next start if the
motor feedback encoder settings have been changed.
• The parameter cannot be changed while the drive is
running.
Done
Done Refreshing done. 0
Refresh Refreshing. 1
91.11 Module 1 type Defines the type of the module used as interface module 1. None
None None (communication disabled). 0
FEN-01 FEN-01. 1
FEN-31 FEN-31. 4
91.12 Module 1 location Specifies the slot 1 on the control unit of the drive into which
the interface module is installed.
Slot 2
Slot 1 Slot 1. 1
91.21 Module 1 temp
sensor type
Specifies the type of temperature sensor connected to
interface module 1. Note that the module must also be
activated by parameters 91.11…91.12.
None
None None. 0
PTC PTC. (The unit is ohms.) 1
KTY-84 KTY84. (The unit is selected by parameter 96.16 Unit
selection.)
2
91.22 Module 1 temp filter
time
Defines a filtering time for the temperature measurement
through interface module 1.
1500 ms
0…10000 ms Filtering time for temperature measurement. -
