ABB ACS860 - Limits; Fault Functions

324 Additional parameter data
28.71 Freq ramp set selection uint32 --1 = 1
28.72 Freq acceleration time 1 real32 0.000 …1800.000 s 1000 = 1 s
28.73 Freq deceleration time 1 real32 0.000 …1800.000 s 1000 = 1 s
28.74 Freq acceleration time 2 real32 0.000 …1800.000 s 1000 = 1 s
28.75 Freq deceleration time 2 real32 0.000 …1800.000 s 1000 = 1 s
28.76 Freq ramp in zero source uint32 --1 = 1
28.77 Freq ramp hold uint32 --1 = 1
28.78 Freq ramp output balancing real32 -100.00 … 500.00 Hz 100 = 1 Hz
28.79 Freq ramp out balancing
enable
uint32 --1 = 1
28.90 Frequency ref act 1 real32 -100.00 … 100.00 Hz 100 = 1 Hz
28.91 Frequency ref act 2 real32 -100.00 … 100.00 Hz 100 = 1 Hz
28.92 Frequency ref act 3 real32 -100.00 … 100.00 Hz 100 = 1 Hz
28.96 Frequency ref act 7 real32 -100.00 … 100.00 Hz 100 = 1 Hz
28.97 Frequency ref unlimited real32 -100.00 … 100.00 Hz 100 = 1 Hz
30 Limits
30.01 Limit word 1 uint16 0000h…FFFFh - 1 = 1
30.02 Torque limit status uint16 0000h…FFFFh - 1 = 1
30.11 Minimum speed real32 -6000.00 … 6000.00 rpm 100 = 1 rpm
30.12 Maximum speed real32 -6000.00 … 6000.00 rpm 100 = 1 rpm
30.13 Minimum frequency real32 -100.00 … 100.00 Hz 100 = 1 Hz
30.14 Maximum frequency real32 -100.00 … 100.00 Hz 100 = 1 Hz
30.17 Maximum current real32 0.00 … 30000.00 A 100 = 1 A
30.18 Minimum torque sel uint32 --1 = 1
30.19 Minimum torque 1 real32 -1600.0 … 0.0 % 10 = 1%
30.20 Maximum torque 1 real32 0.0 … 1600.0 % 10 = 1%
30.21 Minimum torque 2 source uint32 --1 = 1
30.22 Maximum torque 2 source uint32 --1 = 1
30.23 Minimum torque 2 real32 -1600.0 … 0.0 % 10 = 1%
30.24 Maximum torque 2 real32 0.0 … 1600.0 % 10 = 1%
30.25 Maximum torque sel uint32 --1 = 1
30.26 Power motoring limit real32 0.00 … 600.00 % 100 = 1%
30.27 Power generating limit real32 -600.00 … 0.00 % 100 = 1%
30.30 Overvoltage control uint16 0…1 - 1 = 1
30.31 Undervoltage control uint16 0…1 - 1 = 1
30.35 Thermal current limitation uint16 0…1 - 1 = 1
31 Fault functions
31.01 External event 1 source uint32 --1 = 1
31.02 External event 1 type uint16 0…3 - 1 = 1
31.03 External event 2 source uint32 --1 = 1
31.04 External event 2 type uint16 0…3 - 1 = 1
No. Name Type Range Unit FbEq32
