110 Parameters
06.47 Follower CW user
bit 2 selection
Selects a binary source whose status is transmitted as bit 14
of the Follower control word to follower drives. (Bits 0…11 of
the Follower control word are taken from 06.01 Main control
word.)
MCW user bit
2
False 0. 0
True 1. 1
MCW user bit 0 Bit 12 of 06.01 Main control word (see page 102). 2
MCW user bit 1 Bit 13 of 06.01 Main control word (see page 102). 3
MCW user bit 2 Bit 14 of 06.01 Main control word (see page 102). 4
MCW user bit 3 Bit 15 of 06.01 Main control word (see page 102). 5
Other [bit] Source selection (see Terms and abbreviations on page 92). -
06.48 Follower CW user
bit 3 selection
Selects a binary source whose status is transmitted as bit 15
of the Follower control word to follower drives. (Bits 0…11 of
the Follower control word are taken from 06.01 Main control
word.)
MCW user bit
3
False 0. 0
True 1. 1
MCW user bit 0 Bit 12 of 06.01 Main control word (see page 102). 2
MCW user bit 1 Bit 13 of 06.01 Main control word (see page 102). 3
MCW user bit 2 Bit 14 of 06.01 Main control word (see page 102). 4
MCW user bit 3 Bit 15 of 06.01 Main control word (see page 102). 5
Other [bit] Source selection (see Terms and abbreviations on page 92). -
07
07 System info
Information on drive hardware, firmware and application
program.
All parameters in this group are read-only.
07.03 Drive rating id Type of the drive/inverter unit. -
07.04 Firmware name Firmware identification.
The format is QGKFX, where X denotes the control unit type
(2 or B = BCU-01, 6 or C = ZCU-02/04).
-
07.05 Firmware version Version number of the firmware.
The format is A.BB.C.D, where A = major version, B = minor
version, C = patch (ie. firmware variant code), D = 0.
-
07.06 Loading package
name
Name of the firmware loading package.
The format is QGKLX, where X denotes the control unit type
(2 or B = BCU-02, 6 or C = ZCU-02/04).
-
07.07 Loading package
version
Version number of the firmware loading package. See
parameter 07.05.
-
07.08 Bootloader version Version number of the firmware bootloader. -
07.11 Cpu usage Microprocessor load in percent. -
0…100% Microprocessor load. 1 = 1%
07.13 PU logic version
number
Version number of the power unit logic.
The value of FFFF indicates that the version numbers of
parallel-connected power units are different. See the drive
information on the control panel.
-
07.15 FPGA logic version
number
Version number of the FPGA logic of the control unit. -
No. Name/Value Description Def/FbEq16
