102 Parameters
05.04 Fan on-time
counter
Running time of the drive cooling fan. Can be reset from the
control panel by keeping Reset depressed for over 3 seconds.
-
0…65535 d Cooling fan run-time counter. 1 = 1 d
05.09 Time from power-up 500-microsecond ticks elapsed since the last boot of the
control unit.
-
0…4294967295 500-microsecond ticks since last boot. 1 = 1
05.11 Inverter
temperature
Estimated drive temperature in percent of fault limit. The
actual trip temperature varies according to the type of the
drive.
0.0% = 0 °C
94% approx. = Warning limit
100.0% = Fault limit
-
-40.0 … 160.0% Drive temperature in percent. 1 = 1%
05.22 Diagnostic word 3 Diagnostic word 3. -
0000h…FFFFh Diagnostic word 3. 1 = 1
06
06 Control and status
words
Drive control and status words.
06.01 Main control word The main control word of the drive. This parameter shows the
control signals as received from the selected sources (such as
digital inputs, the fieldbus interfaces and the application
program).
The bit assignments of the word are as described on page
413. The related status word and state diagram are presented
on pages 414 and 415 respectively.
Notes:
• Bits 12…15 can be used to carry additional control data,
and used as a signal source by any binary-source selector
parameter. Bit 10 must be active for bits 12…15 to update.
• In fieldbus control, this parameter value is not exactly the
same as the control word that the drive receives from the
PLC. See parameter 50.12 FBA A debug mode.
This parameter is read-only.
-
0000h…FFFFh Main control word. 1 = 1
06.02 Application control
word
The drive control word received from the application program
(if any). The bit assignments are described on page 413.
This parameter is read-only.
-
0000h…FFFFh Application program control word. 1 = 1
No. Name/Value Description Def/FbEq16
Bit Name Value
0…10 Reserved
11 Fan command 1 = Drive fan is rotating above idle speed
counter 1 = Drive fan service counter has reached its limit
13…15 Reserved
