314 Additional parameter data
04.44 Event word 1 bit 1 aux code uint32 0000 0000h …
FFFF FFFFh
- 1 = 1
…… ………
04.71 Event word 1 bit 15 code uint16 0000h…FFFFh - 1 = 1
04.72 Event word 1 bit 15 aux code uint32 0000 0000h …
FFFF FFFFh
- 1 = 1
04.120 Fault/Warning word
compatibility
uint16 0…1 - 1 = 1
05 Diagnostics
05.01 On-time counter uint16 0…65535 d 1 = 1 d
05.02 Run-time counter uint16 0…65535 d 1 = 1 d
05.04 Fan on-time counter uint16 0…65535 d 1 = 1 d
05.09 Time from power-up uint32 0…4294967295 - 1 = 1
05.11 Inverter temperature real32 -40.0 … 160.0 % 10 = 1%
05.22 Diagnostic word 3 uint16 0000h…FFFFh - 1 = 1
06 Control and status words
06.01 Main control word uint16 0000h…FFFFh - 1 = 1
06.02 Application control word uint16 0000h…FFFFh - 1 = 1
06.03 FBA A transparent control
word
uint32 00000000h…FFFFFFFFh - 1 = 1
06.05 EFB transparent control word uint32 00000000h…FFFFFFFFh -
06.11 Main status word uint16 0000h…FFFFh - 1 = 1
06.16 Drive status word 1 uint16 0000h…FFFFh - 1 = 1
06.17 Drive status word 2 uint16 0000h…FFFFh - 1 = 1
06.18 Start inhibit status word uint16 0000h…FFFFh - 1 = 1
06.19 Speed control status word uint16 0000h…FFFFh - 1 = 1
06.20 Constant speed status word uint16 0000h…FFFFh - 1 = 1
06.21 Drive status word 3 uint16 0000h…FFFFh - 1 = 1
06.25 Drive inhibit status word 2 uint16 0000h…FFFFh - 1 = 1
06.29 MSW bit 10 sel uint32 --1 = 1
06.30 MSW bit 11 sel uint32 --1 = 1
06.31 MSW bit 12 sel uint32 --1 = 1
06.32 MSW bit 13 sel uint32 --1 = 1
06.33 MSW bit 14 sel uint32 --1 = 1
(Parameters 06.36…06.43 only visible when supply unit control activated by 95.20)
06.45 Follower CW user bit 0
selection
uint32 --1 = 1
06.46 Follower CW user bit 1
selection
uint32 --1 = 1
06.47 Follower CW user bit 2
selection
uint32 --1 = 1
06.48 Follower CW user bit 3
selection
uint32 --1 = 1
No. Name Type Range Unit FbEq32
