274 Parameters
62
62 D2D and DDCS
receive data
Mapping of data received through the DDCS link.
See also parameter group 60 DDCS communication.
62.01 M/F data 1
selection
(Follower only) Defines a target for the data received as word
1 from the master through the master/follower link.
See also parameter 62.25 MF data 1 value.
None
None None. 0
CW 16bit Control Word (16 bits) 1
Ref1 16bit Reference REF1 (16 bits) 2
Ref2 16bit Reference REF2 (16 bits) 3
Other Source selection (see Terms and abbreviations on page 92). -
62.02 M/F data 2
selection
(Follower only) Defines a target for the data received as word
2 from the master through the master/follower link.
See also parameter 62.26 MF data 2 value.
For the selections, see parameter 62.01 M/F data 1 selection.
None
62.03 M/F data 3
selection
(Follower only) Defines a target for the data received as word
3 from the master through the master/follower link.
See also parameter 62.27 MF data 3 value.
For the selections, see parameter 62.01 M/F data 1 selection.
None
62.04 Follower node 2
data 1 sel
Defines a target for the data received as word 1 from the first
follower (ie. the follower with node address 2) through the
master/follower link.
See also parameter 62.28 Follower node 2 data 1 value.
Follower SW
None None. 0
Follower SW Status word of the follower. See also parameter 60.18
Follower enable.
26
Other Source selection (see Terms and abbreviations on page 92). -
62.05 Follower node 2
data 2 sel
Defines a target for the data received as word 2 from the first
follower (ie. the follower with node address 2) through the
master/follower link.
See also parameter 62.29 Follower node 2 data 2 value.
For the selections, see parameter 62.04 Follower node 2 data
1 sel.
None
62.06 Follower node 2
data 3 sel
Defines a target for the data received as word 3 from the first
follower (ie. the follower with node address 2) through the
master/follower link.
See also parameter 62.30 Follower node 2 data 3 value.
For the selections, see parameter 62.04 Follower node 2 data
1 sel.
None
62.25 MF data 1 value (Follower only) Displays, in integer format, the data received
from the master as word 1.
Parameter 62.01 M/F data 1 selection can be used to select a
target for the received data. This parameter can also be used
as a signal source by other parameters.
0
0…65535 Data received as word 1 in master/follower communication.
62.26 MF data 2 value (Follower only) Displays, in integer format, the data received
from the master as word 2.
Parameter 62.02 M/F data 2 selection can be used to select a
target for the received data. This parameter can also be used
as a signal source by other parameters.
0
0…65535 Data received as word 2 in master/follower communication.
No. Name/Value Description Def/FbEq16
