ABB ACS860 - Supervision

210 Parameters
31.43 Main fan fault
acknowledge
Activates/deactivates (and selects the source for) R8i module
main fan status (acknowledgement) supervision.
When a main fan fault (unexpected state of the
acknowledgement signal) is detected, the drive reacts as
defined by parameter 31.35 main fault function?
0 = Main fan fault
1 = Main fan OK
Not selected
Not selected 0. 0
Selected 1. 1
DI1 Digital input DI1 (10.02 DI delayed status, bit 0). 2
DI2 Digital input DI2 (10.02 DI delayed status, bit 1). 3
DI3 Digital input DI3 (10.02 DI delayed status, bit 2). 4
DI4 Digital input DI4 (10.02 DI delayed status, bit 3). 5
DI5 Digital input DI5 (10.02 DI delayed status, bit 4). 6
DI6 Digital input DI6 (10.02 DI delayed status, bit 5). 7
DIO1 Digital input/output DIO1 (11.02 DIO delayed status, bit 0). 10
DIO2 Digital input/output DIO2 (11.02 DIO delayed status, bit 1). 11
Other [bit] Source selection (see Terms and abbreviations on page 84). -
31.54 Fault action Selects the stop mode when a non-critical fault occurs. Coast
Coast The drive coasts to a stop. 0
Emergency ramp The drive follows the ramp specified for an emergency stop in
parameter 23.23 Emergency stop time.
1
32
32 Supervision
Configuration of signal supervision functions 1…3.
Three values can be chosen to be monitored; a warning or
fault is generated whenever predefined limits are exceeded.
See also section Signal supervision (page 71).
32.01 Supervision status Signal supervision status word.
Indicates whether the values monitored by the signal
supervision functions are within or outside their respective
limits.
Note: This word is independent of the drive actions defined by
parameters 32.06, 32.16 and 32.26.
0000b
0000…0111b Signal supervision status word. 1 = 1
32.05 Supervision 1
function
Selects the mode of signal supervision function 1. Determines
how the monitored signal (see parameter 32.07) is compared
to its lower and upper limits (32.09 and 32.10 respectively).
The action to be taken when the condition is fulfilled is
selected by 32.06.
Disabled
Disabled Signal supervision 1 not in use. 0
No. Name/Value Description Def/FbEq16
Bit Name Description
0 Supervision 1 active 1 = Signal selected by 32.07 is outside its limits.
1 Supervision 2 active 1 = Signal selected by 32.17 is outside its limits.
2 Supervision 3 active 1 = Signal selected by 32.27 is outside its limits.
3…15 Reserved
