330 Additional parameter data
46.03 Torque scaling real32 0.1 … 1000.0 % 10 = 1%
46.04 Power scaling real32 0.10 … 30000.00 kW kW 100 = 1 unit
46.05 Current scaling real32 0…30000 A 1 = 1 A
46.06 Speed ref zero scaling real32 0.00 … 30000.00 rpm 100 = 1 rpm
46.07 Frequency ref zero scaling real32 0.00 … 1000.00 Hz 100 = 1 Hz
46.11 Filter time motor speed real32 0…20000 ms 1 = 1 ms
46.12 Filter time output frequency real32 0…20000 ms 1 = 1 ms
46.13 Filter time motor torque real32 0…20000 ms 1 = 1 ms
46.14 Filter time power out real32 0…20000 ms 1 = 1 ms
46.21 At speed hysteresis real32 0.00 … 6000.00 rpm 100 = 1 rpm
46.22 At frequency hysteresis real32 0.00 … 100.00 Hz 100 = 1 Hz
46.23 At torque hysteresis real32 0.0 … 300.0 % 1 = 1%
46.31 Above speed limit real32 0.00 …6000.00 rpm 100 = 1 rpm
46.32 Above frequency limit real32 0.00 … 100.00 Hz 100 = 1 Hz
46.33 Above torque limit real32 0.0 … 1600.0 % 10 = 1%
46.42 Torque decimals uint16 0…2 - 1 = 1
47 Data storage
47.01 Data storage 1 real32 real32 Defined by 47.31 - 1000 = 1
47.02 Data storage 2 real32 real32 Defined by 47.32 - 1000 = 1
47.03 Data storage 3 real32 real32 Defined by 47.33 - 1000 = 1
47.04 Data storage 4 real32 real32 Defined by 47.34 - 1000 = 1
47.05 Data storage 5 real32 real32 Defined by 47.35 - 1000 = 1
47.06 Data storage 6 real32 real32 Defined by 47.36 - 1000 = 1
47.07 Data storage 7 real32 real32 Defined by 47.37 - 1000 = 1
47.08 Data storage 8 real32 real32 Defined by 47.38 - 1000 = 1
47.11 Data storage 1 int32 int32 -2147483648 …
2147483647
- 1 = 1
47.12 Data storage 2 int32 int32 -2147483648 …
2147483647
- 1 = 1
47.13 Data storage 3 int32 int32 -2147483648 …
2147483647
- 1 = 1
47.14 Data storage 4 int32 int32 -2147483648 …
2147483647
- 1 = 1
47.15 Data storage 5 int32 int32 -2147483648 …
2147483647
- 1 = 1
47.16 Data storage 6 int32 int32 -2147483648 …
2147483647
- 1 = 1
47.17 Data storage 7 int32 int32 -2147483648 …
2147483647
- 1 = 1
47.18 Data storage 8 int32 int32 -2147483648 …
2147483647
- 1 = 1
47.21 Data storage 1 int16 int16 -32768 … 32767 - 1 = 1
47.22 Data storage 2 int16 int16 -32768 … 32767 - 1 = 1
47.23 Data storage 3 int16 int16 -32768 … 32767 - 1 = 1
No. Name Type Range Unit FbEq32
