Additional parameter data 339
91.22 Module 1 temp filter time real32 0…10000 ms 1 = 1 ms
92 Encoder 1 configuration
92.01 Encoder 1 type uint16 0…7 - 1 = 1
92.02 Encoder 1 source uint16 1…2 - 1 = 1
Other parameters in this group when a TTL, TTL+ and HTL encoder is selected
(92.17, 92.23…92.25 visible depending on encoder type selection)
92.10 Pulses/revolution uint16 0…65535 - 1 = 1
92.11 Pulse encoder type uint16 0…1 - 1 = 1
92.12 Speed calculation mode uint16 0…5 - 1 = 1
92.14 Speed estimation enable uint16 0…1 - 1 = 1
92.15 Transient filter uint16 0…3 - 1 = 1
92.17 Accepted pulse freq of
encoder 1
uint16 0…300 kHz 1 = 1 kHz
92.21 Encoder cable fault mode uint16 0…3 - 1 = 1
92.23 Maximum pulse waiting time real32 1…200 ms 1 = 1 ms
92.24 Pulse edge filtering uint16 0…2 - 1 = 1
92.25 Pulse overfrequency function uint16 0…1 - 1 = 1
Other parameters in this group when an absolute encoder is selected
95 HW configuration
95.01 Supply voltage uint16 0…6 - 1 = 1
95.02 Adaptive voltage limits uint16 0…1 - 1 = 1
95.04 Control board supply uint16 0…2 - 1 = 1
(Parameter 95.08 only visible with a ZCU control unit)
95.08 DC switch monitoring uint16 0…1 - 1 = 1
(Parameters 95.09…95.14 only visible with a BCU control unit)
95.09 Switch fuse controller uint16 0…1 - 1 = 1
95.13 Reduced run mode uint16 0…65535 - 1 = 1
95.14 Connected modules uint16 0000h…FFFFh - 1 = 1
95.20 HW options word 1 uint16 0000h…FFFFh - 1 = 1
(Parameters 95.30…95.31 only visible with a BCU control unit)
95.30 Parallel type list filter uint16 1…5 - 1 = 1
95.31 Parallel type configuration uint16 --1 = 1
95.40 Transformation ratio real32 0.000 … 100.000 - 1000 = 1
96 System
96.01 Language uint16 --1 = 1
96.02 Pass code uint32 0…99999999 - 1 = 1
96.03 Access levels active uint16 0000h…FFFFh - 1 = 1
96.04 Macro select uint16 0…6 - 1 = 1
96.05 Macro active uint16 1…6 - 1 = 1
96.06 Parameter restore uint16 --1 = 1
96.07 Parameter save manually uint16 0…1 - 1 = 1
No. Name Type Range Unit FbEq32
