ABB ACS860 - Generic Timer & Counter

Parameters 213
Abs high Action is taken whenever the absolute value of the signal rises
above its (absolute) upper limit.
4
Both Action is taken whenever the signal falls below its low limit or
rises above its high limit.
5
Abs both Action is taken whenever the absolute value of the signal falls
below its (absolute) low limit or rises above its (absolute) high
limit.
6
32.26 Supervision 3
action
Selects the action the drive takes when the value monitored
by signal supervision 3 exceeds its limits.
Note: This parameter does not affect the status indicated by
32.01 Supervision status.
No action
No action No action taken. 0
Warning A warning (A8B2 Signal supervision 3) is generated. 1
Fault The drive trips on 80B2 Signal supervision 3.2
Fault if running If running, the drive trips on 80B2 Signal supervision 3.3
32.27 Supervision 3
signal
Selects the signal to be monitored by signal supervision
function 3.
For the available selections, see parameter 32.07 Supervision
1 signal.
Zero
32.28 Supervision 3 filter
time
Defines a filter time constant for the signal monitored by signal
supervision 3.
0.000 s
0.000 … 30.000 s Signal filter time. 1000 = 1 s
32.29 Supervision 3 low Defines the lower limit for signal supervision 3. 0.00
-21474830.00 …
21474830.00
Low limit. -
32.30 Supervision 3 high Defines the upper limit for signal supervision 3. 0.00
-21474830.00 …
21474830.00
Upper limit. -
33
33 Generic timer &
counter
Configuration of maintenance timers/counters.
See also section Maintenance timers and counters (page 71).
33.01 Counter status Displays the maintenance timer/counter status word,
indicating which maintenance timers/counters have exceeded
their limits.
This parameter is read-only.
-
0000 0000b …
0011 1111b
Maintenance time/counter status word. 1 = 1
No. Name/Value Description Def/FbEq16
Bit Name Description
0 On-time1 1 = On-time timer 1 has reached its preset limit.
1 On-time2 1 = On-time timer 2 has reached its preset limit.
2 Edge 1 1 = Signal edge counter 1 has reached its preset limit.
3 Edge 2 1 = Signal edge counter 2 has reached its preset limit.
4 Value 1 1 = Value counter 1 has reached its preset limit.
5 Value 2 1 = Value counter 2 has reached its preset limit.
6…15 Reserved
