358 Fault tracing
A88C Device clean Warning generated by an on-
time timer.
Programmable warnings:
33.14 On-time 1 warn message
33.24 On-time 2 warn message
Check the auxiliary code. Check the
source of the warning corresponding to
the code:
0: 33.13 On-time 1 source
1: 33.23 On-time 2 source
10: 05.04 Fan on-time counter.
A88D DC capacitor
A88E Cabinet fan
A88F Cooling fan
A890 Additional cooling
A8A0 AI supervision
Programmable warning:
12.03 AI supervision
function
An analog signal is outside the
limits specified for the analog
input.
Check the auxiliary code (format XYY).
“X” specifies the location of the input (0:
AI on control unit), “YY” specifies the
input and limit (01: AI1 under minimum,
02: AI1 over maximum, 03: AI2 under
minimum, 04: AI2 over maximum).
Check signal level at the analog input.
Check the wiring connected to the input.
Check the minimum and maximum limits
of the input in parameter group 12
Standard AI.
A8B0 Signal supervision
(Editable message text)
Programmable warning:
32.06 Supervision 1 action
Warning generated by the
signal supervision 1 function.
Check the source of the warning
(parameter 32.07 Supervision 1 signal).
A8B1 Signal supervision 2
(Editable message text)
Programmable warning:
32.16 Supervision 2 action
Warning generated by the
signal supervision 2 function.
Check the source of the warning
(parameter 32.17 Supervision 2 signal).
A8B2 Signal supervision 3
(Editable message text)
Programmable warning:
32.26 Supervision 3 action
Warning generated by the
signal supervision 3 function.
Check the source of the warning
(parameter 32.27 Supervision 3 signal).
A981 External warning 1
(Editable message text)
Programmable warning:
31.01 External event 1
source
31.02 External event 1
type
Fault in external device 1. Check the external device.
Check setting of parameter 31.01
External event 1 source.
A982 External warning 2
(Editable message text)
Programmable warning:
31.03 External event 2
source
31.04 External event 2
type
Fault in external device 2. Check the external device.
Check setting of parameter 31.03
External event 2 source.
A983 External warning 3
(Editable message text)
Programmable warning:
31.05 External event 3
source
31.06 External event 3
type
Fault in external device 3. Check the external device.
Check setting of parameter 31.05
External event 3 source.
A984 External warning 4
(Editable message text)
Programmable warning:
31.07 External event 4
source
31.08 External event 4
type
Fault in external device 4. Check the external device.
Check setting of parameter 31.07
External event 4 source.
Code
(hex)
Warning Cause What to do
