340 Additional parameter data
96.08 Control board boot uint16 0…1 - 1 = 1
96.10 User set status uint16 ---
96.11 User set save/load uint16 ---
96.12 User set I/O mode in1 uint32 ---
96.13 User set I/O mode in2 uint32 ---
96.20 Time sync primary source uint16 0…9 - 1 = 1
96.24 Full days since 1st Jan 1980 uint16 1…59999 - 1 = 1
96.25 Time in minutes within 24 h uint16 0…1439 - 1 = 1
96.26 Time in ms within one minute uint16 0…59999 - 1 = 1
96.29 Time sync source status uint16 0000h…FFFFh - 1 = 1
96.31 Drive ID number uint16 0…32767 - 1 = 1
96.39 Power up event logging uint16 0…1 - 1 = 1
96.51 Clear fault and event logger uint16 0…65535 - 1 = 1
96.53 Actual checksum uint32 00000000h…FFFFFFFFh - 1 = 1
96.54 Checksum action uint16 0…4 - 1 = 1
96.55 Checksum control word uint16 0000h…FFFFh - 1 = 1
96.56 Approved checksum 1 uint32 00000000h…FFFFFFFFh - 1 = 1
96.57 Approved checksum 2 uint32 00000000h…FFFFFFFFh - 1 = 1
96.58 Approved checksum 3 uint32 00000000h…FFFFFFFFh - 1 = 1
96.59 Approved checksum 4 uint32 00000000h…FFFFFFFFh - 1 = 1
96.61 User data logger status word uint16 0000h…FFFFh - 1 = 1
96.63 User data logger trigger uint32 ---
96.64 User data logger start uint32 ---
96.65 Factory data logger time level uint16 --1 = 1
96.70 Disable adaptive program uint16 0…1 - 1 = 1
(Parameters 96.100…96.102 only visible when enabled by parameter 96.02)
96.100 Change user pass code uint32 10000000…99999999 - 1 = 1
96.101 Confirm user pass code uint32 10000000…99999999 - 1 = 1
96.102 User lock functionality uint16 0000h…FFFFh - 1 = 1
(Parameter 96.108 only visible when IGBT supply unit control activated by 95.20)
96.108 LSU control board boot uint16 0…1 - 1 = 1
97 Motor control
97.03 Slip gain real32 0…200 % 1 = 1%
97.04 Voltage reserve real32 -4…50 % 1 = 1%
97.05 Flux braking uint16 0…2 - 1 = 1
97.06 Flux reference select uint32 --1 = 1
97.07 User flux reference real32 0.00 … 200.00 % 100 = 1%
97.09 Switching freq mode uint16 0…3 - 1 = 1
97.11 TR tuning real32 25…400 % 1 = 1%
97.13 IR compensation real32 0.00 … 50.00 % 100 = 1%
No. Name Type Range Unit FbEq32
