Application macros 87
 Selection of constant speeds
By default, constant speeds 1…7 are selected using digital inputs DI4…DI6 as
follows:
 Default parameter settings for the Sequential control macro
Below is a listing of default parameter values that differ from those listed for the
Factory macro in Parameter listing (page 95).
Parameter
Sequential control macro
default
No. Name
20.12 Run enable 1 source DIIL
21.03 Stop mode Ramp
22.21 Constant speed function 01b (Bit 0 = Packed)
22.22 Constant speed sel1 DI4
22.23 Constant speed sel2 DI5
22.24 Constant speed sel3 DI6
22.27 Constant speed 2 600.00 rpm
22.28 Constant speed 3 900.00 rpm
22.29 Constant speed 4 1200.00 rpm
22.30 Constant speed 5 1500.00 rpm
22.31 Constant speed 6 2400.00 rpm
22.32 Constant speed 7 3000.00 rpm
23.11 Ramp set selection DI3
25.06 Acc comp derivation time 0.12 s
31.11 Fault reset selection Not selected
DI4 DI5 DI6 Constant speed active
000
None (External speed
reference used)
1 0 0 Constant speed 1
0 1 0 Constant speed 2
1 1 0 Constant speed 3
0 0 1 Constant speed 4
1 0 1 Constant speed 5
0 1 1 Constant speed 6
1 1 1 Constant speed 7
