ABB ACS860 - Generic Timer & Counter

326 Additional parameter data
32.09 Supervision 1 low real32 -21474830.00 …
21474830.00
- 100 = 1
32.10 Supervision 1 high real32 -21474830.00 …
21474830.00
- 100 = 1
32.15 Supervision 2 function uint16 0…6 - 1 = 1
32.16 Supervision 2 action uint16 0…3 - 1 = 1
32.17 Supervision 2 signal uint32 --1 = 1
32.18 Supervision 2 filter time real32 0.000 … 30.000 s 1000 = 1 s
32.19 Supervision 2 low real32 -21474830.00 …
21474830.00
- 100 = 1
32.20 Supervision 2 high real32 -21474830.00 …
21474830.00
- 100 = 1
32.25 Supervision 3 function uint16 0…6 - 1 = 1
32.26 Supervision 3 action uint16 0…3 - 1 = 1
32.27 Supervision 3 signal uint32 --1 = 1
32.28 Supervision 3 filter time real32 0.000 … 30.000 s 1000 = 1 s
32.29 Supervision 3 low real32 -21474830.00 …
21474830.00
- 100 = 1
32.30 Supervision 3 high real32 -21474830.00 …
21474830.00
- 100 = 1
33 Generic timer & counter
33.01 Counter status uint16 000000b…111111b - 1 = 1
33.10 On-time 1 actual uint32 0…4294967295 s 1 = 1 s
33.11 On-time 1 warn limit uint32 0…4294967295 s 1 = 1 s
33.12 On-time 1 function uint16 00b…11b - 1 = 1
33.13 On-time 1 source uint32 --1 = 1
33.14 On-time 1 warn message uint32 --1 = 1
33.20 On-time 2 actual uint32 0…4294967295 s 1 = 1 s
33.21 On-time 2 warn limit uint32 0…4294967295 s 1 = 1 s
33.22 On-time 2 function uint16 00b…11b - 1 = 1
33.23 On-time 2 source uint32 --1 = 1
33.24 On-time 2 warn message uint32 --1 = 1
33.30 Edge counter 1 actual uint32 0…4294967295 - 1 = 1
33.31 Edge counter 1 warn limit uint32 0…4294967295 - 1 = 1
33.32 Edge counter 1 function uint16 0000b…1111b - 1 = 1
33.33 Edge counter 1 source uint32 --1 = 1
33.34 Edge counter 1 divider uint32 1…4294967295 - 1 = 1
33.35 Edge counter 1 warn message uint32 --1 = 1
33.40 Edge counter 2 actual uint32 0…4294967295 - 1 = 1
33.41 Edge counter 2 warn limit uint32 0…4294967295 - 1 = 1
33.42 Edge counter 2 function uint16 0000b…1111b - 1 = 1
33.43 Edge counter 2 source uint32 --1 = 1
33.44 Edge counter 2 divider uint32 1…4294967295 - 1 = 1
No. Name Type Range Unit FbEq32
