Parameters 211
Low Action is taken whenever the signal falls below its lower limit. 1
High Action is taken whenever the signal rises above its upper limit. 2
Abs low Action is taken whenever the absolute value of the signal falls
below its (absolute) lower limit.
3
Abs high Action is taken whenever the absolute value of the signal rises
above its (absolute) upper limit.
4
Both Action is taken whenever the signal falls below its low limit or
rises above its high limit.
5
Abs both Action is taken whenever the absolute value of the signal falls
below its (absolute) low limit or rises above its (absolute) high
limit.
6
32.06 Supervision 1
action
Selects the action the drive takes when the value monitored
by signal supervision 1 exceeds its limits.
Note: This parameter does not affect the status indicated by
32.01 Supervision status.
No action
No action No action taken. 0
Warning A warning (A8B0 Signal supervision) is generated. 1
Fault The drive trips on 80B0 Signal supervision.2
Fault if running If running, the drive trips on 80B0 Signal supervision.3
32.07 Supervision 1
signal
Selects the signal to be monitored by signal supervision
function 1.
Zero
Zero None. 0
Speed 01.01 Motor speed used (page 95). 1
Frequency 01.06 Output frequency (page 95). 3
Current 01.07 Motor current (page 95). 4
Torque 01.10 Motor torque (page 95). 6
DC voltage 01.11 DC voltage (page 95). 7
Output power 01.14 Output power (page 95). 8
AI1 12.11 AI1 actual value
(page 125). 9
AI2 12.21 AI2 actual value (page 127). 10
Speed ref ramp in 23.01 Speed ref ramp input (page 157). 18
Speed ref ramp out 23.02 Speed ref ramp output (page 157). 19
Speed ref used 24.01 Used speed reference (page 162). 20
Torque ref used 26.02 Torque reference used (page 178). 21
Freq ref used 28.02 Frequency ref ramp output (page 186). 22
Other Source selection (see Terms and abbreviations on page 92). -
32.08 Supervision 1 filter
time
Defines a filter time constant for the signal monitored by signal
supervision 1.
0.000 s
0.000 … 30.000 s Signal filter time. 1000 = 1 s
32.09 Supervision 1 low Defines the lower limit for signal supervision 1. 0.00
-21474830.00 …
21474830.00
Low limit. -
32.10 Supervision 1 high Defines the upper limit for signal supervision 1. 0.00
-21474830.00 …
21474830.00
Upper limit. -
No. Name/Value Description Def/FbEq16
