Additional parameter data 313
03 Input references
03.01 Panel reference real32 -100000.00 … 100000.00 - 100 = 1
03.02 Panel reference 2 real32 -30000.00 … 30000.00 - 100 = 1
03.05 FB A reference 1 real32 -100000.00 … 100000.00 - 100 = 1
03.06 FB A reference 2 real32 -100000.00 … 100000.00 - 100 = 1
03.09 EFB reference 1 real32 -30000.00 … 30000.00 - 100 = 1
03.10 EFB reference 2 real32 -30000.00 … 30000.00 - 100 = 1
03.11 DDCS controller ref 1 real32 -30000.00 … 30000.00 - 100 = 1
03.12 DDCS controller ref 2 real32 -30000.00 … 30000.00 - 100 = 1
03.13 M/F or D2D ref1 real32 -30000.00 … 30000.00 - 100 = 1
03.14 M/F or D2D ref2 real32 -30000.00 … 30000.00 - 100 = 1
03.51 IEC application panel
reference
real32 -100000.0 … 100000.0 - 1 = 1
04 Warnings and faults
04.01 Tripping fault uint16 0000h…FFFFh - 1 = 1
04.02 Active fault 2 uint16 0000h…FFFFh - 1 = 1
04.03 Active fault 3 uint16 0000h…FFFFh - 1 = 1
04.04 Active fault 4 uint16 0000h…FFFFh - 1 = 1
04.05 Active fault 5 uint16 0000h…FFFFh - 1 = 1
04.06 Active warning 1 uint16 0000h…FFFFh - 1 = 1
04.07 Active warning 2 uint16 0000h…FFFFh - 1 = 1
04.08 Active warning 3 uint16 0000h…FFFFh - 1 = 1
04.09 Active warning 4 uint16 0000h…FFFFh - 1 = 1
04.10 Active warning 5 uint16 0000h…FFFFh - 1 = 1
04.11 Latest fault uint16 0000h…FFFFh - 1 = 1
04.12 2nd latest fault uint16 0000h…FFFFh - 1 = 1
04.13 3rd latest fault uint16 0000h…FFFFh - 1 = 1
04.14 4th latest fault uint16 0000h…FFFFh - 1 = 1
04.15 5th latest fault uint16 0000h…FFFFh - 1 = 1
04.16 Latest warning uint16 0000h…FFFFh - 1 = 1
04.17 2nd latest warning uint16 0000h…FFFFh - 1 = 1
04.18 3rd latest warning uint16 0000h…FFFFh - 1 = 1
04.19 4th latest warning uint16 0000h…FFFFh - 1 = 1
04.20 5th latest warning uint16 0000h…FFFFh - 1 = 1
(Parameter 04.25 only visible with a BCU control unit)
04.25 Faulted modules uint16 0000h…FFFFh - 1 = 1
04.40 Event word 1 uint16 0000h…FFFFh - 1 = 1
04.41 Event word 1 bit 0 code uint16 0000h…FFFFh - 1 = 1
04.42 Event word 1 bit 0 aux code uint32 0000 0000h …
FFFF FFFFh
-1 = 1
04.43 Event word 1 bit 1 code uint16 0000h…FFFFh - 1 = 1
No. Name Type Range Unit FbEq32
