Parameters 103
06.03 FBA A transparent
control word
Displays the unaltered control word received from the PLC
through fieldbus adapter A when a transparent
communication profile is selected eg. by parameter group 51
FBA A settings. See section Control word and Status word
(page 410).
This parameter is read-only.
-
00000000h …
FFFFFFFFh
Control word received through fieldbus adapter A. -
06.05 EFB transparent
control word
Displays the unaltered control word received from the PLC
through the embedded fieldbus interface when a transparent
communication profile is selected in parameter 58.25 Control
profile. See section The Transparent profile (page 400).
This parameter is read-only.
-
00000000h …
FFFFFFFFh
Control word received through the embedded fieldbus
interface.
1 = 1
06.11 Main status word Main status word of the drive.
The bit assignments are described on page 414. The related
control word and state diagram are presented on pages 413
and 415 respectively.
Note: In fieldbus control, this parameter value is not exactly
the same as the status word that the drive sends to the PLC.
See parameter 50.12 FBA A debug mode.
This parameter is read-only.
-
0000h…FFFFh Main status word. 1 = 1
No. Name/Value Description Def/FbEq16
