Parameters 109
True 1. 1
Ext ctrl loc Bit 11 of 06.01 Main control word (see page 102). 2
Other [bit] Source selection (see Terms and abbreviations on page 92). -
06.31 MSW bit 12 sel Selects a binary source whose status is transmitted as bit 12
of 06.11 Main status word.
Ext run
enable
False 0. 0
True 1. 1
Ext run enable Inverted bit 5 of 06.18 Start inhibit status word (see page 106). 2
Other [bit] Source selection (see Terms and abbreviations on page 92). -
06.32 MSW bit 13 sel Selects a binary source whose status is transmitted as bit 13
of 06.11 Main status word.
False
False 0. 0
True 1. 1
Other [bit] Source selection (see Terms and abbreviations on page 92). -
06.33 MSW bit 14 sel Selects a binary source whose status is transmitted as bit 14
of 06.11 Main status word.
False
False 0. 0
True 1. 1
Other [bit] Source selection (see Terms and abbreviations on page 92). -
06.45 Follower CW user
bit 0 selection
Selects a binary source whose status is transmitted as bit 12
of the Follower control word to follower drives. (Bits 0…11 of
the Follower control word are taken from 06.01 Main control
word.)
See also section Master/follower functionality (page 30).
MCW user bit
0
False 0. 0
True 1. 1
MCW user bit 0 Bit 12 of 06.01 Main control word (see page 102). 2
MCW user bit 1 Bit 13 of 06.01 Main control word (see page 102
). 3
MCW user bit 2 Bit 14 of 06.01 Main control word (see page 102). 4
MCW user bit 3 Bit 15 of 06.01 Main control word (see page 102). 5
Other [bit] Source selection (see Terms and abbreviations on page 92). -
06.46 Follower CW user
bit 1 selection
Selects a binary source whose status is transmitted as bit 13
of the Follower control word to follower drives. (Bits 0…11 of
the Follower control word are taken from 06.01 Main control
word.)
MCW user bit
1
False 0. 0
True 1. 1
MCW user bit 0 Bit 12 of 06.01 Main control word (see page 102). 2
MCW user bit 1 Bit 13 of 06.01 Main control word (see page 102). 3
MCW user bit 2 Bit 14 of 06.01 Main control word (see page 102). 4
MCW user bit 3 Bit 15 of 06.01 Main control word (see page 102). 5
Other [bit] Source selection (see Terms and abbreviations on page 92). -
No. Name/Value Description Def/FbEq16
