320 Additional parameter data
22.51 Critical speed function uint16 00b…11b - 1 = 1
22.52 Critical speed 1 low real32 -6000.00 … 6000.00 rpm 100 = 1 rpm
22.53 Critical speed 1 high real32 -6000.00 … 6000.00 rpm 100 = 1 rpm
22.54 Critical speed 2 low real32 -6000.00 … 6000.00 rpm 100 = 1 rpm
22.55 Critical speed 2 high real32 -6000.00 … 6000.00 rpm 100 = 1 rpm
22.56 Critical speed 3 low real32 -6000.00 … 6000.00 rpm 100 = 1 rpm
22.57 Critical speed 3 high real32 -6000.00 … 6000.00 rpm 100 = 1 rpm
22.71 Motor potentiometer function uint16 0…2 - 1 = 1
22.72 Motor potentiometer initial
value
real32 -32768.00 … 32767.00 - 100 = 1
22.73 Motor potentiometer up source uint32 --1 = 1
22.74 Motor potentiometer down
source
uint32 --1 = 1
22.75 Motor potentiometer ramp time real32 0.0 … 3600.0 s 10 = 1 s
22.76 Motor potentiometer min value real32 -32768.00 … 32767.00 - 100 = 1
22.77 Motor potentiometer max
value
real32 -32768.00 … 32767.00 - 100 = 1
22.80 Motor potentiometer ref act real32 -32768.00 … 32767.00 - 100 = 1
22.81 Speed reference act 1 real32 -6000.00 … 6000.00 rpm 100 = 1 rpm
22.82 Speed reference act 2 real32 -6000.00 … 6000.00 rpm 100 = 1 rpm
22.83 Speed reference act 3 real32 -6000.00 … 6000.00 rpm 100 = 1 rpm
22.84 Speed reference act 4 real32 -6000.00 … 6000.00 rpm 100 = 1 rpm
22.85 Speed reference act 5 real32 -6000.00 … 6000.00 rpm 100 = 1 rpm
22.86 Speed reference act 6 real32 -6000.00 … 6000.00 rpm 100 = 1 rpm
22.87 Speed reference act 7 real32 -6000.00 … 6000.00 rpm 100 = 1 rpm
23 Speed reference ramp
23.01 Speed ref ramp input real32 -6000.00 … 6000.00 rpm 100 = 1 rpm
23.02 Speed ref ramp output real32 -6000.00 … 6000.00 rpm 100 = 1 rpm
23.11 Ramp set selection uint32 --1 = 1
23.12 Acceleration time 1 real32 0.000 …1800.000 s 1000 = 1 s
23.13 Deceleration time 1 real32 0.000 …1800.000 s 1000 = 1 s
23.14 Acceleration time 2 real32 0.000 …1800.000 s 1000 = 1 s
23.15 Deceleration time 2 real32 0.000 …1800.000 s 1000 = 1 s
23.16 Shape time acc 1 real32 0.000 …1800.000 s 1000 = 1 s
23.17 Shape time acc 2 real32 0.000 …1800.000 s 1000 = 1 s
23.18 Shape time dec 1 real32 0.000 …1800.000 s 1000 = 1 s
23.19 Shape time dec 2 real32 0.000 …1800.000 s 1000 = 1 s
23.20 Acc time jogging real32 0.000 …1800.000 s 1000 = 1 s
23.21 Dec time jogging real32 0.000 …1800.000 s 1000 = 1 s
23.23 Emergency stop time real32 0.000 …1800.000 s 1000 = 1 s
23.24 Speed ramp in zero source uint32 --1 = 1
23.26 Ramp out balancing enable uint32 --1 = 1
No. Name Type Range Unit FbEq32
