Program features 73
Amplitude logger 1 is fixed to monitor motor current, and cannot be reset. With
amplitude logger 1, 100% corresponds to the maximum output current of the drive
(I
max
, as given in the hardware manual). The distribution of collected samples is
shown by parameters 36.20…36.29.
Settings
Parameter group 36 Load analyzer (page 229).
Percentage of samples
<10%
10…20%
20…30%
30…40%
40…50%
50…60%
60…70%
70…80%
80…90%
>90%
Amplitude ranges
(parameters 36.40…36.49)
