116 Cabinet construction
2×D8T modules in Rittal TS 8 enclosure (12-pulse)
# Installation stage Instruction code Kit code Kit ordering code
1. Installation of common parts:
• Baying parts
• PE busbar [PE]
• Divider panel
• Bracket for Flat-PLS busbar
holder (common AC)
• Bracket for Flat-PLS busbar
holder (common DC)
• 3AUA0000114534
• 3AUA0000114474
• 3AUA0000115695
• 3AUA0000115893
• 3AUA0000115891
A-468-X-011
A-468-X-001
3AUA0000115905
3AUA0000115906
2. Module installation parts 3AXD50000001886 A-6-8-305 3AXD50000002489
3. Quick connector installation 3AXD50000001904
3AXD50000001886
A-468-8-100 3AUA0000119227
4. DC busbars 3AXD50000001867 A-6-8-202 3AXD50000002490
5. AC busbars to quick connector 3AXD50000001866 A-6-8-182 3AXD50000002493
6. AC busbars to main AC
installation
3AXD50000010218 A-6-8-105 3AXD50000008819
7. Module installation
• DC connection flanges
3AUA0000118641 -
A-468-8-230
-
3AXD50000002639
8. Shroud installation 3AXD50000001901 A-6-8-354 3AXD50000002439
