Ordering information 239
 Supply unit AC fuses
These fuses protect the supply module for short circuits. Supply unit AC fuses are used in
such ACS880-04 configurations that there is a main circuit breaker, or a main switch-
disconnector and a main contactor in case of two or more supply modules (6-pulse) or four
or more supply modules (12-pulse). For the dimension drawings, see section AC fuses on
page 382.
 Main contactors
You can use the main contactors for the on-off control of the AC input power. The
contactors can make and break the full load current.
The contactor package includes:
• contactor unit
• fixing screws
• 2 × normally-open + 2 × normally-closed auxiliary contacts.
For the dimension drawings, see section Main contactor on page 378.
 Varistor kit (UL/CSA)
See page 200.
ACS880-04-… Fuse (IEC) Qty Ordering code
Type Data
U
N
= 500 V (Range 380 … 500 V)
1800A-5 170M6419 1600 A, 690 V 6 68393108
1980A-5 170M6419 1600 A, 690 V 6 68393108
U
N
= 690 V (Range 525 … 690 V)
1450A-7 170M6417 1400 A, 690 V 6 3AXD50000000150
1650A-7 170M6417 1400 A, 690 V 6 3AXD50000000150
ACS880-04-…
Fuse (UL, CSA) Qty Ordering code
Type Data
U
N
= 500 V (Range 380 … 500 V)
1800A-5 170M6419 1600 A, 690 V 6 68393108
1980A-5 170M6419 1600 A, 690 V 6 68393108
U
N
= 690 V (Range 525 … 690 V)
1450A-7 170M6417 1400 A, 690 V 6 3AXD50000000150
1650A-7 170M6417 1400 A, 690 V 6 3AXD50000000150
ACS880-04-… Main contactor (IEC) Qty Ordering code
Type Information
U
N
= 500 V (Range 380 … 500 V)
1800A-5 AF2050-30-22-70 2050 A (I
Th
), 1000 V (U
e
) 1 3AUA0000051805
1980A-5 AF2050-30-22-70 2050 A (I
Th
), 1000 V (U
e
) 1 3AUA0000051805
U
N
= 690 V (Range 525 … 690 V)
1450A-7 AF2050-30-22-70 2050 A (I
Th
), 1000 V (U
e
) 1 3AUA0000051805
1650A-7 AF2050-30-22-70 2050 A (I
Th
), 1000 V (U
e
) 1 3AUA0000051805
