Ordering information 225
 Main switch-disconnectors and main circuit breakers
You must equip the electric supply of a machinery with a main disconnecting device
(IEC/EN60204-1). The main power line is equipped with a main switch-disconnector or a
main circuit breaker [Q1]. This section lists suitable main switch-disconnectors/main circuit
breakers.
Note: For some of the IEC high power units, you can use withdrawable main circuit
breaker instead of the main switch-disconnector. In the table below, these high power units
are marked with *.
ACS880-04-… Main switch-disconnector (230 V,
IEC)
Qty Ordering code Shaft
Type Data Type Dimensions
D
mm
L
mm
U
N
= 400 V (Range 380 … 415 V)
1250A-3* SWITCH KIT OT-
TYPE IEC 2000 E12
55 kA, 1000 V,
2000 A
1 3AXD50000006186 OXP12X465 12 465
1480A-3* SWITCH KIT OT-
TYPE IEC 2000 E12
55 kA, 1000 V,
2000 A
1 3AXD50000006186 OXP12X465 12 465
1760A-3* SWITCH KIT OT-
TYPE IEC 2000 E12
55 kA, 1000 V,
2000 A
1 3AXD50000006186 OXP12X465 12 465
U
N
= 500 V (Range 380 … 500 V)
1320A-5* SWITCH KIT OT-
TYPE IEC 2000 E12
55 kA, 1000 V,
2000 A
1 3AXD50000006186 OXP12X465 12 465
1450A-5* SWITCH KIT OT-
TYPE IEC 2000 E12
55 kA, 1000 V,
2000 A
1 3AXD50000006186 OXP12X465 12 465
1580A-5* SWITCH KIT OT-
TYPE IEC 2000 E12
55 kA, 1000 V,
2000 A
1 3AXD50000006186 OXP12X465 12 465
U
N
= 690 V (Range 525 … 690 V)
1160A-7 SWITCH KIT OT-
TYPE IEC 1250 E12
1250 A,
1000 V, 50 kA
1 3AXD50000006185 OXP12X395 12 395
Shaft dimensions
D Shaft diameter
L Shaft length
