268 Ordering information
2×D7T + 2×R8i, 12-pulse
ACS880-04 single drive module packages
Delivery of the ACS880-04 single drive module package includes the following items:
Note: The following components are always required to construct a working unit and must
be ordered separately:
• BCU control unit kits (one for supply, one for inverter),
• fiber optic cables,
• RDCO-04C DDCS communication option modules (68882915, one for supply, one for
inverter),
• common mode filters (consists of two toroidal cores, 2 × 3AUA0000032859) for each
inverter module,
• control circuit plug connectors (3AUA0000059813) for each module,
• quick connectors (3AUA0000119227) for each module.
Suitable kits and components for each ACS880-04 type are listed in this chapter.
The other parts listed in this chapter
• may be required by the application, or
• make the installation or use of the module easier.
Ordering code Contents and option codes
U
N
= 400 V (Range 380 … 415 V):
ACS880-04-0990A-3+A004
U
N
= 500 V (Range 380 … 500 V):
ACS880-04-0990A-5+A004
U
N
= 690 V (Range 525 … 690 V):
ACS880-04-0800A-7+A004
• Supply and inverter modules with speed-controlled cooling
fans
•+C132: Marine type approval. For more information, see
ACS880 +C132 marine type-approved drive modules and
module packages supplement (3AXD50000037752
[English]).
• +C183: Heating element mounted to module base
• +C188: Direct-on-line cooling fan
• +E205: Internal du/dt filters
• +G304: 115 V auxiliary voltage supply
