ControlMaster CM10, CM30 and CM50
Universal process controllers,
1
/8,
1
/4 and
1
/2 DIN 7 Advanced Level
IM/CM/S–EN Rev. R 99
070.040
(066.041)
Tuner 1 (2) Abort
Autotune has been aborted by the user. –
094.034
(090.035)
Valve 1 (2) Sticking
Motorized valve travel time is significantly slower than
configured time.
Check valve to identify reason for sticking.
Check correct travel time is entered in configuration.
168.026 (166.027)
(164.028)
Tuner 1
Phase 1..3
Autotune is in progress. See page 29 for details of each
phase.
Autotune can be aborted if required by selecting Manual
control mode.
160.030
(158.031)
156.032)
Tuner 2
Phase 1..3
Autotune is in progress. See page 29 for details of each
phase.
Autotune can be aborted if required by selecting Manual
control mode.
162.029
(154.033)
Tuner 1 (2) Pass
Autotune has completed successfully and calculated
new control parameters.
Acknowledge diagnostic
178.025
In Configuration
The device is currently in the configuration mode.
This is for use with remote access via digital
communications.
Icon
Number /
Message
Possible Cause Suggested Action
Table 7.1 Diagnostic Messages (Continued)
