ABB ControlMaster CM10 User Manual

ControlMaster CM10, CM30 and CM50
Universal process controllers,
1
/8,
1
/4 and
1
/2 DIN Appendix A – Digital and Analog Sources
IM/CM/S–EN Rev. R 117
A.2 Analog Sources
Loop 1 Ctrl Track Control track state
Math Block 1 (8) Fail Maths failure
RTA 1 (2) State Real time alarm state
Softkey Toggle
Front panel soft key toggles the source’s
state.
Softkey Edge
Front panel soft key sets the source active
on key press.
T1 (2) Int Pulse
Totalizer intermediate pulse. Active for
1 second when the intermediate count is
reached.
T1 (2) Run State
Totalizer run state
1 = totalizer running
T1 (2) Wrap Pulse
Totalizer wrap pulse
If Wrap Enable is set to On – active for 1
second when the predetermined count is
reached.
If set to Off – active when the
predetermined count has been reached
and remains active until the totalizer is
reset.
Source Name Description [Comment]
Source Name Description
Anlg IP 1 (4) Analog input
Constant 1 (8) Math block constant
Linearizer 1 (2) Custom linearizer
Loop 1 Control OP Control output value
Loop 1 Deviation Loop 1 deviation
Loop 1 LSP Local setpoint loop
Loop 1 PV Loop 1 process variable
Loop 1 SP Loop control setpoint
Loop 1 Split OP1 Loop 1 split output
Loop 1 Valve Pos Motorized valve position
Loop Bias 1 Loop 1 desired bias
Math Block 1 (8) Math block
