/2 DIN Appendix D – Output Type Assignments
124 IM/CM/S–EN Rev. R
Appendix D – Output Type Assignments
Output Type AO 1 AO 2 DIO 1 DIO 2 RLY1 RLY2 RLY3 RLY4
Analog OP PV ALM 1ALM 2ALM 3ALM 4
Time Proportioning PV SP OP ALM 1ALM 2ALM 3
MValve + Feedback PV SP Open V Close V ALM 1 ALM 2
MValve Boundless PV SP OP 2 Open V Close V ALM 1 ALM 2
Split Output
Analog / Relay
OP 1 PV OP 2 ALM 1ALM 2ALM 3
Split Output
Analog / Digital
OP 1 PV OP 2 ALM 1ALM 2ALM 3ALM 4
Split Output
Relay / Relay
PV SP OP 1 OP 2 ALM 1 ALM 2
Split Output
Relay / Digital
PV SP OP 2 OP 1 ALM 1ALM 2ALM 3
Split Output
Digital / Relay
PV SP OP 1 OP 2 ALM 1ALM 2ALM 3
Split Output
Digital / Digital
PV SP OP 1 OP 2 ALM 1ALM 2ALM 3ALM 4
Split Output
Analog / Analog
OP 1 OP 2 ALM 1ALM 2ALM 3ALM 4
