Page #29 background image
ControlMaster CM10, CM30 and CM50
Universal process controllers,
1
/8,
1
/4 and
1
/2 DIN 6 Basic Level
IM/CM/S–EN Rev. R 27
6Basic Level
The Basic menu provides access to the tunable control settings and setpoint values.
Menu
Basic
Loop 1 Setpoints
Local Setpoint 1 (4) The local setpoint value required. If this value is adjusted in the Operator Level (see page 22) its
value here is also updated.
RSP Ratio If the remote (external) setpoint is selected, the control setpoint value is (ratio x remote
setpoint input) + bias.
Note. This parameter is available only if the template selected has remote setpoint – see page
101.
RSP Bias Sets the remote setpoint bias in engineering units.
Note. This parameter is available only if template selected has remote setpoint or ratio.
