ControlMaster CM10, CM30 and CM50
Universal process controllers,
1
/8,
1
/4 and
1
/2 DIN 7 Advanced Level
36 IM/CM/S–EN Rev. R
7 Advanced Level
7.1 Device Setup
Provides access to standard setup parameters to determine the type of control / indication required. Also
provides the ability to create non-standard configurations for special application requirements.
Initial Setup
App Template Application templates enable standard configurations for particular applications to be
created as simply as possible. Select the appropriate template before configuring any other
parameters. When a template is selected, the controller assumes the preset form for that
template. The inputs and function blocks are soft-wired automatically to perform the
selected function.
Note. See Section 8, page 101 for templates available to controllers with Standard
functionality.
Loop 1 Output Type The appropriate output function block, relay, digital and analog outputs are configured and
soft-wired – see Appendix D, page 124 for output assignments.
Loop 1 Split O/P These types of outputs split the Control (PID) output signal (see page 30) into 2 signals. The
linear relationship between the PID output and the 2 outputs can be configured in the control
configuration.
To Next Page
