ControlMaster CM10, CM30 and CM50
Universal process controllers,
1
/8,
1
/4 and
1
/2 DIN 7 Advanced Level
IM/CM/S–EN Rev. R 51
7.4 Control
Enables the setpoints, control functions and outputs to be configured.
Loop 1 Setpoints The controller can configure independent local setpoint values, remote setpoint functionality and
limit the absolute values and rate of change of the control setpoint.
Low Limit
High Limit
The setpoint Low / High Limit parameters define the maximum and minimum values for the local
and / or remote setpoints. Setpoint limits do not apply in Manual control mode with local setpoint
tracking enabled. If the setpoint is out of limits when Auto control mode is selected, the setpoint
value can be adjusted only towards its limits.
No. of Local SP’s Selects the number of independent local (internal) setpoints required. Local setpoints can be
selected from the Operator Level menu (see page 22) or via a digital signal.
Note. 4 Setpoints are available on CM30, CM50 controllers, 2 setpoints are available on CM10
controllers.
Local Setpoint 1 (4) If the value is adjusted in the Operator level, its value here is also updated.
