ABB ControlMaster CM10 User Manual

ControlMaster CM10, CM30 and CM50
Universal process controllers,
1
/8,
1
/4 and
1
/2 DIN 8 Templates and Functionality
IM/CM/S–EN Rev. R 101
8 Templates and Functionality
8.1 Basic Templates
8.1.1 Single Loop / Single Loop with Remote Setpoint
This template provides basic feedback control using three term PID or On/Off control. The controller output is calculated from
the difference between the process variable and the control setpoint. The control setpoint can be a fixed value entered by the
user (Local setpoint) or an input from a remote source (remote setpoint).
Notes.
 Input assignments can be changed in Device Setup / Custom Config – see page 38.
 Output assignments can be changed in Input / Output configuration – see page 43.
