ControlMaster CM10, CM30 and CM50
Universal process controllers,
1
/8,
1
/4 and
1
/2 DIN 4 Installation
IM/CM/S–EN Rev. R 9
4.2 Dimensions
Fig. 4.2 ControlMaster CM10 and CM30 Dimensions
CM10 CM30
Dimensions in mm (in.)
Panel Cut-out
Dimensions
97 (3.81)
97
(3.81)
121 (4.76)
141 (5.55)
91.8
(3.6)
20 (0.78)
92
(3.62)
+0.03
–0
+0.8
–0
92 (3.62)
14 (0.55)
14 (0.55)
30 (1.18)
+0.8 –0
+0.03 –0
50 (1.97)
45 (1.77)
+0.6
–0
+0.02
–0
