ControlMaster CM10, CM30 and CM50
Universal process controllers,
1
/8,
1
/4 and
1
/2 DIN 7 Advanced Level
52 IM/CM/S–EN Rev. R
…Control / …Loop 1 Setpoints
Track Mode The local (internal) setpoint can track another value according to the setpoint tracking mode
selected.
Off
No tracking.
Local
The local (internal) setpoint tracks the process variable when Manual control mode is selected.
Remote
The local (internal) setpoint tracks the remote (external) setpoint when in Remote Setpoint mode. If
the controller is put into Manual control mode, the setpoint reverts from Remote to Local.
Note. Available only if the template selected has remote setpoint functionality.
Local and Remote
Note. Available only if the template selected has remote setpoint functionality.
RSP Ratio When the remote (external) setpoint is selected the control setpoint value is:
(ratio x remote setpoint input) + bias
RSP Bias Sets the remote setpoint bias in engineering units – see Appendix C, page 122 for description of
analog input (engineering) units.
