ControlMaster CM10, CM30 and CM50
Universal process controllers,
1
/8,
1
/4 and
1
/2 DIN 10 Specification
IM/CM/S–EN Rev. R 115
Electrical
Supply ranges
100 to 240 V AC ±10 % (90 V min. to 265 V max.) 50 / 60 Hz
10 to 36 V DC (optional)
Power consumption
10 W max.
Power interruption protection
No effect for interrupts of up to 60 ms
Physical
Size
Weight
Panel cutout
Case material
Glass-filled polycarbonate
DS/CM10–EN Rev. O
DS/CM30–EN Rev. P
DS/CM50–EN Rev. N
CM10 50 x 97 x 141 mm (2.0 x 3.8 x 5.5 in.)
CM30 97 x 97 x 141 mm (3.8 x 3.8 x 5.5 in.)
CM50 144 x 76 x 146 mm (5.6 x 3.0 x 5.7 in.)
CM10 0.38 kg (0.84 lb) approx. (unpacked)
CM30 0.5 kg (1.1 lb) approx. (unpacked)
CM50 0.58 kg (1.3 lb) approx. (unpacked)
CM10 45 x 92 mm (1.8 x 3.6 in.), 121 mm (4.8 in.) behind panel
CM30 92 x 92 mm (3.6 x 3.6 in.), 121 mm (4.8 in.) behind panel
CM50 138 x 68 mm (5.4 x 2.7 in.) 123 mm (4.9 in.)
behind panel
