ControlMaster CM10, CM30 and CM50
Universal process controllers,
1
/8,
1
/4 and
1
/2 DIN 7 Advanced Level
38 IM/CM/S–EN Rev. R
…Device Setup
Security Setup 2 Security access levels are provided, each protected by a password of up to 6
alphanumeric characters.
Note. Passwords are not set at the factory and must be entered by the end user(s).
Basic Password Basic level provides access to the Basic level – see Section 6, page 27.
Advanced Password Provides access to all configuration parameters – see Section 7, page 36.
Reset Passwords Resets all passwords to factory values.
Custom Config
Loop 1 (2) PV
Sets the source for the process variable.
Loop 1 (2) Split O/P
Sets the source for output to the split output function block.
Loop 1 (2) Valve Mode
Sets the valve operation mode, Feedback or Boundless – see page 32.
Loop 1 (2) Valve O/P
Sets the control input to the valve function block.
Loop 1 (2) Valve FB
Sets the source for position feedback input.
Loop 1 (2) TP OP1
Sets the source for control input to the time proportioning block for Output 1 – see page 36.
Loop 1 (2) TP OP2
Sets the source for control input to the time proportioning block for Output 2 see page 36.
Loop 1 (2) RSP
Sets the source for the remote (external) setpoint.
