ControlMaster CM10, CM30 and CM50
Universal process controllers,
1
/8,
1
/4 and
1
/2 DIN 7 Advanced Level
46 IM/CM/S–EN Rev. R
… Input/Output / …Analog Input 1 (4)
Pulse Units Selects the unit of measure for the pulse input type.
Pulse / Unit Sets the number of pulses required to represent 1 pulse unit (as set above), for example, if
Pulse Units = Kl and Pulse / Unit = 10.00000000, each pulse represents 0.1 Kl,
10 pulses = 1 Kl.
Broken Sensor If an input failure occurs, the input value can be configured to drive in a set direction.
None
No action taken.
Automatic
If the value of failed input is below Eng Low (see page 45), the input value is driven to the
minimum downscale value; otherwise it is driven to the maximum upscale value.
Upscale
The input is driven to the maximum upscale value.
Downscale
The input is driven to the minimum downscale value.
To Next Page
