ControlMaster CM10, CM30 and CM50
Universal process controllers,
1
/8,
1
/4 and
1
/2 DIN 7 Advanced Level
48 IM/CM/S–EN Rev. R
…Input/Output / … …Analog Outputs
Elect. Low* The current output required when the source value is equal to the Eng Low value – see page
45.
Elect. High* The current output required when the source value is equal to the Eng High value – see page
45.
Auto Eng Range* If enabled (On) the Eng High and Eng Low values for the output are set to the engineering
range values of the source automatically.
Eng Low* The minimum engineering range output value.
Eng High* The maximum engineering range output value.
Polarity** Sets the polarity of the output signal.
If set to Negative, the output is energized when the source is inactive.
If set to Positive, the output is energized when the source is active.
*Not applicable if Output Type is Digital or Source is None.
**Not applicable if Output Type is Analog or Source is None.
