ControlMaster CM10, CM30 and CM50
Universal process controllers,
1
/8,
1
/4 and
1
/2 DIN 7 Advanced Level
56 IM/CM/S–EN Rev. R
…Control
Loop 1 Output Used to set the output limits, tracking rates, slew rates and output action on power failure or
process variable failure.
Limits Note. When used with split output the limits restrict the PID algorithm output (see page 30) before
the split output range values are calculated.
Limit Action Selects when the output limits should be applied (Off, Auto + Manual, Auto Only).
Low/High Limit Sets minimum / maximum controller output in %.
Failure Actions
Power Recovery Used to select the default power failure mode required following a power interruption or failure.
Last Mode
The last Power Recovery mode selected.
Man – Last
Manual control mode using the last output before power failure.
Man – 0 %
Manual control mode with output set to 0 %.
Man – 100 %
Manual control mode with output set to 100 %.
